COMPulsion v1.2

Five Legendary Compression Types in One Precision Tool.

---

⬇️ Download Demo

---

Overview

COMPulsion delivers authentic analog compression with five meticulously modeled compressor topologies. From the transparent VCA precision to the slow, musical Opto, the aggressive FET attack, the smooth Vari-Mu warmth, and the ultra-clean Modern digital perfection, COMPulsion provides the exact character and response of classic hardware units.

Featuring true Peak and RMS detection, Feedforward/Feedback topologies, profile-specific timing curves, program-dependent release, dual-stage release, and harmonic saturation, COMPulsion is the ultimate compression tool for tracking, mixing, and mastering. Oversampling up to 32x ensures alias-free processing for pristine signal quality.

---

Key Features

🎚️ Five Compressor Topologies

• VCA (Voltage Controlled Amplifier) – Clean, transparent, fast compression (SSL Bus, API 2500)
• FET (Field Effect Transistor) – Fast, aggressive, colored (1176, Distressor)
• Opto (Optical) – Slow, smooth, musical (LA-2A, LA-3A)
• Vari-Mu (Variable Gain Tube) – Smooth, tube warmth (Fairchild, Manley)
• Modern (Digital Perfection) – Ultra-transparent, surgical precision

⚙️ Advanced Compression Engine

• Peak/RMS Detection – Choose between instantaneous peak or smooth RMS detection.
• Feedforward/Feedback Topologies – Authentic compression architectures.
• True feedback behavior matching vintage hardware characteristics.
• 14 Ratio Options – From gentle to extreme limiting: 1:1, 1.5:1, 2:1, 3:1, 4:1, 6:1, 8:1, 10:1, 15:1, 20:1, 30:1, 50:1, 100:1, ∞:1
• Precision Controls – Threshold: -96dB to 0dB (0.1dB steps) | Makeup: 0-24dB (0.1dB steps).
• Profile-Specific Attack/Release – Each topology has calibrated timing curves with independent scaling.
• Hold Time Control – 0-1000ms hold prevents premature release during transients.
• Auto Release – Adaptive release (10ms-2000ms) scales inversely with input level ratio for natural breathing
• Program-Dependent Release – Opto and Vari-Mu profiles analyze 8-sample signal history for 0.5x-2x release scaling based on signal consistency
• Dual-Stage Release – Opto and Vari-Mu feature characteristic fast initial (3.5x) + slow tail (0.35x) release curves with 35%/65% blend
• Fine-Tune Mode – Shift + drag for ultra-precise control (0.1ms – 30 seconds) with adaptive sensitivity.
• Direct Value Entry – Shift + double-click on Attack, Release, Threshold, Makeup, HPF, or LPF to type exact values.
• Profile-Matched Soft Knee – Each topology features authentic knee characteristics.
• Ratio Curve Shaping – Spline-based ratio transitions with profile-specific exponents.
• Response Shape Modeling – Envelope follower curves match hardware behavior.

🎯Lookahead & Precision

• Modern Profile Lookahead – 0-50ms configurable lookahead enables instantaneous attack on transients without overshoot, delivering surgical precision for drum bus and master chain applications.
• De-Click System – Frequency-aware click detection (0-100% intensity) with pattern-based adaptation intelligently eliminates compression artifacts while preserving natural transients.

🔗 Sidechain Processing

• Internal/External Sidechain – Use main signal or external key input with intelligent switching.
• Surgical Precision Filters – 1Hz resolution across 20Hz-20kHz (20,001 frequency options per filter).
• Dual Filter Architecture – Independent HPF (1-20000Hz) and LPF (20000-1Hz) with 4x internal oversampling.
• Linear Phase Mode – FIR filters for zero phase distortion.
• Minimum Phase IIR – Ultra-low latency Butterworth filtering.

🔥 Harmonic Saturation

• Odd Harmonics – Warm, tube-style asymmetric character.
• Even Harmonics – Smooth, tape-style symmetric warmth.
• Mixed Mode – Complex 50/50 blend for rich three-dimensional coloration.
• Profile-Specific THD Curves – Authentic 128-point transfer curves.
• Up to 32x Oversampling – Polyphase IIR half-band filters eliminate aliasing artifacts.
• Asymmetric Bias – 30% bias creates authentic analog-style uneven clipping.
• 5% Smoothing Filter – DC offset prevention with previous-sample blending.

⚡ Total Harmonic Drive (THD)

• Dynamic Saturation – 128-point transfer curve adds level-dependent harmonics (0-200% drive range)
• Profile-Specific Curves – Matched to each topology’s harmonic signature.
• Dual-Stage EQ Shaping – Pre/post shelving for enhanced harmonic character.
• Symmetric/Asymmetric Blending – Symmetric & Asymmetric for complex harmonic content.
• 4x Internal Oversampling – Dedicated polyphase IIR oversampler prevents intermodulation distortion.

⚖️ Parallel Processing

• Wet/Dry Mix – 0-100% blend with sample-accurate smoothing (50ms time constant) for New York-style parallel compression
• Transient Preservation – Blend maintains punch while adding density and RMS level
• Delta Mode – Listen to compressed signal only (wet – dry) for precision compression auditing and effect verification

📊 Real-Time Metering

• Input/Output Meters – Vertical true RMS meters with precise dB readouts (-100dB to 0dB range).
• Clip Indicators – 300ms hold visual warning for 0dBFS peaks.
• Gain Reduction Meter – Horizontal SSL-style meter (0-96dB range).

🎛️ Professional Interface

• Resizable GUI
• Informative Tooltips

🔄 Intelligent DAW Integration

• Latency Compensation – Automatic PDC reporting.
• Sample-Accurate Automation – All parameters support DAW automation.

---

Technical Details

Plugin Type	VST3
Supported OS	Windows 10+
Space Required	6 MB
Version	1.2
